2.00 Box Header H=6.5 Right angle Type

2.00 Box Header H=6.5 Right angle Type

    Part No:3122-XXRXXBK00X2

    Mating: 5224

    Packing: Tube

    Delivery time: 20~25 Day

    UL: Yes

    ROHS Compliant



Inquire Now
Product Details
2D(PDF) Drawing 3D(IGS / STP) Drawing Approval Specification
Current   Rating2.0AMP
Contact Resistance20mΩ   Max
Withstand Voltage500V   AC/DC
Insulation Resistance1000mΩ   Min
Operation Temperature﹣40℃   to +105℃
Contact MaterialBrass
Contact PlatingAu   or Sn over Ni
Insulator MaterialPA9T   +30％GF( UL94V-0 )
CAP MaterialLCP+30%G.F(UL94V-0)
